TAPPI Journal Archive
About TAPPI Journal
As of March 2022, TAPPI Journal’s (TJ) publishing model is 100% Open Access (OA) to improve the accessibility of its published articles, increase researcher engagement and make research more visible. This new format helps researchers meet their funding and grant application requirements and potentially increase the number of citations. As in the past, the copyright remains with the author, and unlike other technical journals, TJ does not require a publication fee. Read more.
Editorial: New coating grades require new tests: Barrier performance inside the package, TAPPI Journal November 2024
November 21, 2022
The TAPPI Journal special Coating issue is an annual issue that focuses on paper coating and coated papers. It is drawn from presentations at TAPPICon and from other submissions on the topic of paper coating. The TAPPICon 2024 Coating track was rich in high-quality technical content. In fact, the papers were of such significance that Coating members of the TAPPI Journal Editorial Board, which include me, Gregg Reed, and Gregory Welsch, decided that a second paper coating-related special issue would be appropriate for the TAPPI Journal editorial calendar. In addition to the current issue on Barrier Coating Testing, there will be another issue on Coating Fundamentals in early 2025.
Quantification of block testing for coated paper substrates, TAPPI Journal November 2024
November 21, 2022
ABSTRACT: Block resistance is a critical property for coated paper and board substrate that will be rolled, stacked, or otherwise contact itself after coating. Small differences in the coated substrate’s blocking can determine whether the substrate can be successfully used for its designated purpose. However, this crucial property is typically evaluated using a qualitative scale that is based on subjective operator ratings and impacted by factors that include: (1) sound of coated substrate during separation, and (2) force with which substrates are separated. This paper tests the hypothesis that quantifying the block test by measuring the force required to peel samples apart improves the test by: (1) providing more standardized testing conditions by controlling peel force and rate; (2) more clearly differentiating samples that experience minimal to some blocking; and (3) maintaining customizability to evaluate customer-specific test conditions. The method developed in this study uses a standard block tester and block testing conditions, but it peels the coated paper samples using a hot tack/heat seal instrument with force measurement capabilities. This paper demonstrates, using the instrument’s heat seal capabilities, that it can measure peel forces that represent the full range of observable block scores. The efficacy of this method was evaluated by having a group of trained operators engage in a randomized, blind experiment where they assessed block resistance on a set of coated paper samples using a modified qualitative block scale and compared their results to force measurements collected using the proposed method. The sample set included two coatings that have successfully run in commercial trials with minimal blocking, and one coating that experienced significant blocking in commercial trials despite only exhibiting some blocking at standard block test conditions in laboratory testing. The quantitative test method presented in this paper clearly differentiated these samples, whereas the qualitative assessment could not predict which samples had suitable block resistance for commercial use. As any tensile tester capable of measuring with 0.1 N resolution can be used for the Quantitative Block Test, the proposed method can be widely adopted. Furthermore, this method can be used for any block condition.
Test method and coating composition impact on measured moisture vapor transmission rate for waterborne coatings on paper, TAPPI Journal November 2024
November 21, 2022
ABSTRACT: Moisture vapor barrier is one of the necessary performance attributes for paper packages. Two methods are typically employed to assess the moisture vapor transmission rate (MVTR): the gravimetric cup method (ASTM E96) and the MOCON method (ASTM F1249). While those tests have been compared for free standing polymeric films, less is understood about their application in coated paper. Our results show that, despite a general agreement between the two methods, discrepancies exist where test protocols and material properties of coated paper impact the MVTR measurement. The measurement discrepancies can be explained by differences in local moisture concentration. Our study provides new insights on moisture vapor barrier assessment of waterborne coatings on paper and implications for achieving paper packages with improved barrier performance.
Orifice geometry as a tool for evaluating extensional flow resistance of barrier coating colors, TAPPI Journal November 2024
November 21, 2022
ABSTRACT: Knowledge of extensional flow behavior of coating colors can be beneficial for improving runnability and eliminating defects in various coating processes. The current work evaluates the use of an orifice geometry attached to a commercial capillary viscometer as a tool to obtain extensional flow properties of barrier coating dispersions. By measuring the pressure drop across the orifice as a function of flow velocity, the method presents the flow resistance as Euler number at industrially relevant high deformation rates. The results agree with the earlier results obtained with a capillary entrance pressure loss technique. The type of polymer additive is shown to control the extensional flow resistance, with high molecular weight linear flexible polymers such as polyethylene oxide (PEO) and polyvinyl alcohol (PVOH) having highest impact. The orifice method offers advantages over other approaches, including the need for only a small sample amount, ease of measurement, and access to high deformation rates.
Experimental investigations into fold cracking of double coated barrier dispersion coatings, TAPPI Journal November 2024
November 21, 2022
ABSTRACT: The trend for replacing single-use plastics with fiber-based barrier coated board packaging has prompted a significant amount of research. There are many proposed ways of providing suitable packaging for applications like food service. Among these are dispersion coated barriers on board, as well as laminated boards that can be produced using conventional polyethylene (PE) or new biodegradable plastics. Minerals have also been shown to be suitable additives to these coatings for improving barrier performance through surface chemistry and by increasing the tortuosity of the pathway through the barrier layer. They also improve the cost effectiveness of the layer by lowering the material cost and raising the solids content, and by improving hold out of the functional layers, leading to a reduction in the amount of barrier coating needed to meet a given performance requirement. Minerals can also aid in the barrier handling in terms of rheology and reduced “stickiness,” as well as blocking of the films. When incorporated as fillers into extruded films, improved adhesion of the film to the board has been reported. One of the remaining challenges is the potential for cracking at the fold during converting and the loss of barrier performance that this can lead to. In this work, we systematically looked at the impact of mineral type and level in a dispersion coating. We assessed the differences in performance resulting from different coating application methods for the precoat layer by looking at the cracking tendency and loss of barrier functionality after folding for both the precoat alone and the final double coated sheets. Barrier results include moisture vapor transmission rate (MVTR), viscous vegetable oil, and the fluid blue stain in industrial methylated spirits (IMS) and Cobb water absorption, both before and after folding.
Evaluation of folding effects on coating damage, TAPPI Journal November 2024
November 21, 2022
ABSTRACT: Barrier coatings on paperboard need to maintain integrity during converting and end-use for effective barrier performance. Folding is one of the most common deformations during converting; however, factors that affect damage during folding are not well defined. This is partly because methods to fold specimens and characterize damage are not standardized and the results are generally not transferable. In this work, we describe a method to fold paper specimens precisely and reproducibly. The keys to folding include using a defined geometry and controlled deformation. Multiple methods can be used to quantify damage; in this case, we use differences in permeability as a measure of how the coating becomes more open. Damage is sensitive to the degree of compression after the initial folding. Using a shim for support provides a defined amount of compression and minimizes the sensitivity to the applied pressure.
